Microsoft Surface Laptop – 13.3″INCH i7 7TH GEN

Processor (CPU)

• Model: Intel Core i7-7660U

• Generation: 7th Gen Kaby Lake

• Cores / Threads: 2 Cores / 4 Threads

• Base Clock: 2.5 GHz

• Max Turbo Boost: Up to 4.0 GHz

• Cache: 4MB L3

• TDP: 15W

Performance Summary:
This is a power-efficient dual-core processor aimed at premium ultraportables. It’s fast enough for web browsing, office productivity, streaming, light design work, and multitasking, but not designed for heavy CPU loads like video rendering or high-end gaming.

🧠 Memory (RAM)

• Size: 8GB

• Type: LPDDR3 (Low Power DDR3)

• Speed: 1866 MHz

• Configuration: Dual-channel (soldered to motherboard – not upgradeable)

Performance Note:
8GB is adequate for most general computing tasks including multiple browser tabs, Office apps, and basic creative work. However, for more intensive workloads or future-proofing, 16GB is generally preferred — but this model is not upgradable.

💾 Storage

• Type: PCIe NVMe Solid State Drive (SSD)

• Capacity: 256GB

• Form Factor: Integrated (not user-replaceable without disassembly)

Performance Summary:
The PCIe SSD provides fast boot times, application launches, and file transfers. However, 256GB may feel limited if you work with a lot of media files or install large applications.

🎨 Graphics

• GPU: Intel Iris Plus Graphics 640

• Shared Memory: Uses system RAM

• DirectX Support: DX12

Performance Summary:
This integrated GPU is more powerful than Intel HD 620 and supports light creative work, light gaming (e.g., League of Legends, Minecraft, older titles), and 4K video playback. It’s not suitable for demanding 3D games or GPU-intensive tasks like 4K video editing.

📺 Display

• Size: 13.5-inch

• Type: PixelSense Touchscreen (10-point multi-touch)

• Resolution: 2256 x 1504

• Pixel Density: 201 PPI

• Aspect Ratio: 3:2 (great for productivity — more vertical space)

• Protection: Corning Gorilla Glass 3

Display Notes:
Excellent color reproduction, sharpness, and touch support. The 3:2 aspect ratio is more comfortable for reading documents and browsing than the common 16:9. Not ideal for widescreen video viewing due to black bars.

🧑‍💻 Keyboard & Input

• Keyboard: Full-size, US English layout, backlit

• Key Travel: 1.5mm (comfortable typing experience)

• Touchpad: Precision glass touchpad – responsive and smooth

• Material: Alcantara fabric palm rest (soft and premium-feeling, but prone to wear/discoloration)

🔌 Ports & Connectivity

• 1 x USB 3.0 Type-A (no USB-C!)

• 1 x Mini DisplayPort

• 1 x 3.5mm Headphone/Mic Combo Jack

• 1 x Surface Connect Port (for charging/docking)

Missing Ports:

• No USB-C / Thunderbolt

• No SD Card Slot

• No HDMI or Ethernet
  (Adapters required for modern connectivity options.)

🌐 Wireless & Networking

• Wi-Fi: 802.11ac (2×2 MIMO), up to 867 Mbps

• Bluetooth: 4.0

🔋 Battery & Power

• Battery Capacity: 45.2 Wh

• Rated Life: Up to 14.5 hours of local video playback (real-world ~8–10 hours for mixed use)

• Charger: 44W Surface power adapter (charges via Surface Connect)

📷 Camera & Audio

• Front Camera: 720p HD (suitable for video calls)

• Microphones: Dual far-field mics

• Speakers: Omnisonic speakers with Dolby Audio Premium

• Biometrics: Windows Hello Face Authentication (via IR camera)

⚖️ Build & Dimensions

• Weight: 1.25 kg (2.76 lbs)

• Dimensions: 308.1 mm x 223.27 mm x 14.48 mm

• Chassis: Aluminum body with soft Alcantara fabric keyboard deck

• Colors: Platinum (most common)

🔐 Security

• Windows Hello facial recognition (no fingerprint sensor)

• TPM chip for enterprise-grade encryption

• Secure boot with UEFI firmware
